SWR-5GE3062 Quad-core ARM 5GE Wireless Router AX3000 WiFi 6 Router
Model Number: SWR-5GE3062
Brand: Softel
MOQ: 1
EasyMESH Function
Quad-core ARM @ 1.7GHz
Next-Gen Gigabit WiFi, Speed up to 3 Gbps
01
Product Description
Chipset
Intel® CPE Wi-Fi Chipset WiFi6 Gig +
Speed
Next-Gen Gigabit WiFi, Speed up to 3 Gbps
Connection
Connect More Devices by OFDMA + MU-MIMO
EasyMesh
Support Wired and Wireless Mesh Connections
Coverage
Maximized Coverage Beamforming
Brief Introduction
SWR-5GE3062 4GE+WiFi6 AX3000 Wireless Router adopts WiFi6 technology which has redefined home WiFi. Experience up to 3X faster speeds, higher capacity, and reduced congestion overall compared to the previous AC WiFi5 standard. The AX3000 4-stream dual-band WiFi6 wireless router reaches a speed of up to 3 Gbps for a buffer-free 4K/HD streaming and gaming experience. The WiFi6 router lets you connect even more devices via OFDMA technology, minimizing network congestion that occurs with too many connected devices. Dual-core processor effortlessly handles all your streaming, gaming, and smart home devices. SWR-5GE3062 uses Beamforming technology to focus WiFi signal to your devices for more reliable coverage, and the EasyMesh protocol-Support wired and wireless Mesh connections.
| SWR-5GE3062 Quad-core ARM 5GE Wireless Router AX3000 WiFi 6 Router | |
| Protocol | Supports standard 802.11ax, concurrent 802.11ax and 802.11a/b/g/n/ac |
| Operating Bands | 802.11b/g/n/ax: 2.4G ~ 2.4835GHz |
| 802.11a/n/ac/ax: 5G: 5.150～5.350GHz, 5.725～5.850GHz | |
| Spatial Streams | Up to 4: 2×2: 2 in 2.4GHz , 2×2: 2 in 5GHz |
| Max Throughput | 2.4G+5G operation mode, maximum throughput per AP: 2.974Gbps, Radio1: 2.4G 0.574Gbps, Radio2: 5G 2.4Gbps |
| Modulation | DSSS: DBPSK@1Mbps, DQPSK@2Mbps and CCK@5.5/11Mbps |
| OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps,
64-QAM@48/54Mbps |
|
| MIMO-OFDM: QPSK, 16QAM, 64QAM, 256QAM, 1024QAM | |
| Transmit Power | <25.5dBm |
| (Vary depending on different countries) | |
| RAM | 256MB |
| Flash | 128MB |
| Dimensions (W x D x H) | 208mm×128mm×158mm |
| Weight | ≤0.4Kg(Unit weight) |
| Installation Mode | Desktop |
| Service Ports | 5*1000M WAN/LAN Ports |
| Power Supply | Local Power Supply (DC 12V) |
| Temperature | Operating Temperature: -5°C to 40°C |
| Storage Temperature: -40°C to 70°C | |
| Humidity | Operating Humidity: 5% to 95% (non-condensing) |
| Storage Humidity: 5% to 95% (non-condensing) | |
| Power Consumption | ＜15W |
| Safety Standard | GB4943,EN60950-1, IEC60950-1 |
| EMC Standard | GB9254,GB17618,EN301 489-1, EN301 489-17 |
| Radio Standard | EN300 328,EN301 893 |
| Working Mode | Routing Mode, Bridge Mode, Wireless Repeater |
| Netwrok Setting | Desplay of Network Information |
| Support Ipv4 address setting | |
| Support Ipv6 address setting | |
| WLAN Setting | Support enable/disable WLAN |
| Support multi SSID setting | |
| Support SSID hiding | |
| Support SSID Name setting | |
| Support SSID encryption setting | |
| Data frame filtering | Support Whitelist, blacklist |
| Intranet settings | Support local area network settings |
| Support DHCP server settings | |
| Support advanced settings (IPv4 / v6 multicast, UPnP) | |
| advanced setting | Support STA control |
| Support WPS | |
| Support 5G Priority (Band Steering) | |
| Support WLAN roaming | |
| Other Function | Support Firewall setting |
| Support network time setting | |
| Support backup and recovery | |
| Support to change login password | |
| Support to upgrade firmware | |
| Support to restart and reset to factory | |
| Support to display Product information | |
| Support to switch network mode | |
| Multicast Service | IPTV |
| Ipv4/v6 multicast | |
WiFi6 Router_SWR-5GE3062 Datasheet-V2.0-EN
