SWR-4GE30W6 Highly integrated Gigabit Ethernet WiFi6 AX3000 Wireless WIFI Router
Model Number: SWR-4GE30W6
Brand: Softel
MOQ: 1
High Performance Chipset
Speed up to 3 Gbps, 160Mhz bandwidth
Support MU-MIMO & OFDMA
01
Product Description
SWR-4GE30W6 (1GE WAN+3GE LAN+WiFi6 AX3000) is an excellent wireless router. With its outstanding performance and excellent cost performance ratio, it has a significant competitive advantage in the market. Its highly integrated design not only makes the device smaller and lighter, but also achieves lower power consumption, which is more green and energy-saving. With WAN/LAN adaptive function, it enhances the flexibility of port usage.SWR-4GE30W6 is equipped with 4 antennas to provide stable network connection while ensuring signal coverage.
In addition, the SWR-4GE30W6 supports mesh networking technology to achieve full Wi-Fi coverage and seamless roaming, providing users with a superior network experience.
| Hardware Parameter | |
| Dimension | 179.9mm* 104. 1mm*30.8mm (L*W*H) |
| Net weight | 185g |
| Working condition | Working temp: -30~+60℃Working humidity:5~95%(non-condensing) |
| Storing condition | Storing temp: -40~+85℃Storing humidity:5~95% (non-condensing) |
| Power adapter | DC 12V, 1A |
| Power supply | ≤12W |
| Interface | 1GE WAN+3GE LAN + WiFi6 |
| Indicators | SYS |
| Button | Reset/WPS |
| Interface Parameter | |
| UserInterface | 4* 10/ 100/ 1000Mbps auto adaptive Ethernet interface , RJ45 connectors( 1*WAN, 3*LAN) |
| WLANInterface | • Compliant with IEEE802 . 11b/g/n/ac/ax• 2402 Mbps on 5GHz and 574Mbps on 2.4 GHz• 2.4GHz: 2*2(3dBi), 5GHz: 2*2(5dBi);External antennas• Maximum number of connected devices:128 |
| Function Data | |
| Management | WEB/Telnet/TR-069/SSH/CLI Management |
| Multicast | •Support IGMP Snooping( IGMPv1/v2/v3)• Support IGMP Proxy• Support MLD Snooping(MLDv1 、MLDv2)• Support MLD Proxy
• Support Fast leave |
| WAN | Maximum speed of 1Gbps |
| Wireless | • Wi-Fi 6: 802. 11a/n/ac/ax 5GHz & 802. 11b/g/n/ax 2.4GHz• WiFi Encryption:WEP-64/WEP-128/ WPA/WPA2/WPA3• Support MU-MIMO & OFDMA• Support Dynamic QoS
• Support 1024-QAM • Support WMM • BSS-Coloring&Beamforming&Beamsteering • Support WIFI Easy-mesh function |
| L3/L4 | • Support IPv4, IPv6 and IPv4/ IPv6 dual stack• Support DHCP/PPPOE/Statics• Support Static route,NAT• Support DMZ, ALG,UPnP
• Support Virtual Server • Support NTP (Network Time Protocol) • Support DNS Client and DNS Proxy |
| DHCP | Support DHCP Server & DHCP Relay |
| Security | • Support local access control• Support IP address filtering• Support URL filtering• Support Anti-DDoS attack function
• Support Anti-port scanning function • Suppression of protocol-specificbroadcast/multicast packets (e.g. DHCP, ARP, IGMP, etc.) • Support Anti-Intranet ARP Attack • Support Parental control function |
