SWR-4GE15W6 1GE WAN 3GE LAN WiFi6 AX1500 2.4G/5G WIFI Router
Model Number: SWR-4GE15W6
Brand: Softel
MOQ: 1
RTL CPU Chipset + Wi-Fi Chipset(2.4GHz With FEM)
Speed up to 1.5 Gbps
Support MU-MIMO & OFDMA
01
Product Description
The SWR-4GE15W6( 1GE WAN+3GE LAN WiFi6 AX1500 Wireless Router) is a powerful and versatile high quality product.
Equipped with 1GE WAN and 3GE LAN interfaces, it also supports the Wi-Fi 6 AX1500 standard, providing users with stable wired and wireless connectivity. Its Realtek solution design ensures excellent performance and reliability. It supports mesh networking technology and is compatible with wireless CPE and PON optical cats for seamless network coverage switching. This router offers excellent price/performance ratio and delivers a sophisticated and high-quality network experience to users.
| Hardware Parameter | |
| Dimension | 200mm*143mm*30mm(L*W*H) |
| Net weight | 0.318kg |
|
Working condition |
Working temp: 0~+50。CWorking humidity:5~90%(non-condensing) |
| Storing condition | Storing temp: -30~~+60。C |
| Power adapter | DC 12V/1A |
| Power supply | ≤10W |
| Interface | 1GE WAN+3GE LAN+ WiFi6 |
| Indicators | STATUS(1), RJ45(3) |
| Button |
Reset, WPS |
| Interface Parameter | |
| User Interface | 4*10/100/1000Mbps auto adaptive Ethernet interface , RJ45 connectors(1*WAN, 3*LAN) |
| WLAN Interface | •Compliant with IEEE802.11b/g/n/ac/ax•1200 Mbps on 5GHz and 300Mbps on 2.4 GHz •2.4Ghz: 2*2, 5GHz: 2*2; 4*4dBi External antennas
•Maximum number of connected devices: 32 for 2.4GHz and 32 for 5GHz |
| Function Data | |
| Management | WEB/Telnet/TR-069/Cloud Management |
| Multicast | • Support IGMP v1/v2/v3• Support IGMP Proxy an Snooping |
| WAN | Maximum speed of 1Gbps |
|
Wireless |
• Wi-Fi 6: 802.11a/n/ac/ax 5GHz & 802.11b/g/n 2.4GHz• WiFi Encryption: WPA/WPA2/WPA3 personal, WPS2.0• Support MU-MIMO & OFDMA
• Support Beamforming • Support Beamsteering • Support WIFI Easy-mesh function |
|
L3/L4 |
• Support IPv4, IPv6 and IPv4/IPv6 dual stack• Support DHCP/PPPOE/Statics• Support Static route,NAT
• Support DMZ, ALG,UPnP • Support Virtual Server • Support NTP (Network Time Protocol) • Support DNS Client and DNS Proxy |
| DHCP | Support DHCP Server & DHCP Relay |
|
Security |
• Support local access control• Support IP address filtering• Support URL filtering
• Support Anti-DoS attack function • Support Anti-port scanning function • Suppression of protocol-specific broadcast/multicast packets (e.g. DHCP, ARP, IGMP, etc.) • Support Anti-Intranet ARP Attack • Support Parental control function |
