SR1002 FTTB Bidirectional Fiber Optical Receiver with Optical AGC
Model Number: SR1002
Brand: Softel
MOQ: 1
Low Power Consumption GaAs Chips
Adopt Advanced Optical AGC Technology
Support Remote Network Management (Optional)
01
Product Description
Brief Overview
SR1002 optical receiver is our latest 1GHz CATV/FTTB bidirectional optical receiver. With a wide range of receiving optical power, high output level, and low power consumption. It is the ideal equipment to build a high-performance NGB network.
Performance Characteristics
- Adopt advanced optical AGC technique, optical AGC control range: +2dBm ～ -9/-8/-7/-6/-5/-4dBm adjustable;
- Forward working frequency extended to 1GHz, RF amplifier part adopts the high-performance low power consumption GaAs chip, the maximum output level up to 106dBuv;
- EQ and ATT both use the professional electric control circuit, making the control more accurate, and operation more convenient;
- Built-in the standard II class network management responder.
- Support remote network management (optional);
- With a compact structure, and convenient installation, it is the first choice equipment for the FTTB CATV network;
- Built-in high-reliability low power consumption power supply;
- Customized logo and Packing Design Available
|
SR1002 FTTB Bidirectional Fiber Optical Receiver with Optical AGC |
||||
|
Item |
Unit |
Technical Parameters |
||
|
Optical Parameters |
||||
|
Receiving Optical Power |
dBm |
-9 ~ +2 |
||
|
Optical AGC Range |
dBm |
+2 ～ -9/-8/-7/-6/-5/-4 (adjustable) |
||
|
Optical Return Loss |
dB |
>45 |
||
|
Optical Receiving Wavelength |
nm |
1100 ~ 1600 |
||
|
Optical Connector Type |
|
SC/APC or specified by the user |
||
|
Fiber Type |
|
Single mode |
||
|
Link performance |
||||
|
C/N |
dB |
≥ 51 |
Note1 |
|
|
C/CTB |
dB |
≥ 60 |
||
|
C/CSO |
dB |
≥ 60 |
||
|
RF Parameters |
||||
|
Frequency Range |
MHz |
45/87 ~862/1003 |
||
|
Flatness in Band |
dB |
±0.75 |
||
|
|
FZ110 output |
FP204 output |
||
|
Rated Output Level |
dBμV |
≥ 108 |
≥ 104 |
|
|
Max Output Level |
dBμV |
≥ 108 (-9 ~ +2dBm Optical power receiving) |
≥ 104 (-9 ~ +2dBm Optical power receiving) |
|
|
≥ 112 (-7 ~ +2dBm Optical power receiving) |
≥ 108 (-7 ~ +2dBm Optical power receiving) |
|||
|
Output Return Loss |
dB |
≥16 |
||
|
Output Impedance |
Ω |
75 |
||
|
Electrical control EQ range |
dB |
0～15 |
||
|
Electrical control ATT range |
dBμV |
0～15 |
||
