ONTX-S104GUV High Speed 20km Transmission Distance 10GE XGSPON ONU
Model Number: ONTX-S104GUV
Brand: Softel
MOQ: 1
10G PON Solution Realtek Chipset
10GE High Speed Port
IPv4/IPv6 Dual Stack
01
Product Description
Brief Introduction
The 10G PON ONT developed by SOFTEL supports dual modes including XG-PON/XGS-PON, providing multiple rate Ethernet ports of 10GE/GE. It enables fast and stable networking for multiple devices, ensuring a seamless user experience within homes and effortlessly meeting the demands of 4K/8K, VR, and other services. It offers home and enterprise users an ultimate experience of 10G ultra-high-speed internet connection.
| Hardware Parameter | |
| Dimension | 180mm*120mm*34.5mm (L*W*H) |
| Operating condition | Operating temp:-10 ~ +55°C
Operating humidity:5 ~ 95% (non-condensed) |
| Storing condition | Storing temp: -40 ~ +70°C
Storing humidity: 5 ~ 95% (non-condensed) |
| Power adapter | 12V/1A |
| Power supply | 12W |
| Interface | 1*10GE+4*GE+1*USB3.0 |
| Indicators | PWR, PON, LOS, WAN, LAN1~5, USB |
| Interface parameter | |
| PON Interface | 10G PON port: Class B+
SC single mode, SC/UPC connector TX optical power: 8dBm RX sensitivity: -29.5dBm Overload optical power: -7dBm Transmission distance: 20km Wavelength: XG(S)-PON:DS 1577nm/US 1270nm |
| 10G PON layer | ITU-T G.987(XG-PON)ITU-T G.9807.1 (XGS-PON) |
| User interface | 1*10GE, Auto-negotiation,RJ45 ports4*GE, Auto-negotiation,RJ45 ports1*USB3.0 |
| USB | 1×USB 3.0 for Shared Storage |
| Function Data | |
| O&M | WEB/TELNET/OAM/OMCI/TR069
Support private OAM/OMCI protocol and Unified network management of VSOL OLT |
| Internet connection | Support Bridge/Router mode |
| Multicast | IGMP v1/v2/v3, IGMP snooping
MLD v1/v2 snooping |
| L2 | 802.1D&802.1ad bridge, 802.1p Cos,802.1Q VLAN |
| L3 | IPv4/IPv6, DHCP Client/Server,PPPoE, NAT, DMZ, DDNS |
| Firewall | Anti-DDOS, Filtering Based on ACL/MAC /URL |
