FTTH 4GE+2*POTS+1*USB3.0+WiFi5 XPON ONT
Model Number: ONT-4GE-2V-DW
Brand: Softel
MOQ: 1
IPv4/IPv6 Dual Stack
WiFi 5 Dual Band 1200Mbps
ZTE XPON Chipset + MTK Wi-Fi Chipset
01
Product Description
Summary
Introducing ONT-4GE-2V-DW (4GE+1POTS/2POTS +WiFi5+USB3.0 XPON HGU ONT) - a revolutionary broadband access device ideal for FTTH and triple play services. This all-in-one device adopts the latest IPv4/IPv6 dual-stack technology and WiFi 5 dual-band 1200Mbps, ensuring lightning-fast internet speed for an unparalleled user experience.
The SOFTEL XPON ONT adopts ZTE XPON chipset and MTK Wi-Fi chipset, supports XPON dual-mode technology, including EPON and GPON, and provides IEEE802.11b/g/n/ac WiFi technology for excellent data transmission capability. Layer 2/Layer 3 features further enhance its performance, making it ideal for carrier-grade FTTH applications.
In addition, ONT is compatible with OAM/OMCI protocol, and various services can be easily configured and managed on SOFTEL OLT. The provided USB 3.0 interface also allows shared storage and printer access for a more seamless experience.
Designed with reliability and ease of management in mind, the ONT ensures you can enjoy uninterrupted services and provides QoS guarantees for various applications. It complies with various international technical standards such as IEEE802.3ah and ITU-T G.984, making it a reliable and versatile choice for all your broadband needs.
| ONT-4GE-2V-DW 4GE+2*POTS+1*USB3.0+WiFi5 XPON ONT | |
| Dimension | 205mm×140mm×37mm(L×W×H) |
| Net weight | 0.32Kg |
| Operating condition | Operating temp:0 ~ +55°C |
| Operating humidity:5 ~ 90% (non-condensed) | |
| Storing condition | Storing temp: -30 ~ +60°C |
| Storing humidity: 5 ~ 90% (non-condensed) | |
| Power adapter | DC 12V,1.5A, external AC-DC power adaptor |
| Power supply | ≤10W |
| Interface | HG3221D-4G1S2NAC:4GE+1POTS+USB3.0+WiFi5 |
| ONT-4GE-2V-DW:4GE+2POTS+USB3.0+WiFi5 | |
| Indicators | PWR,PON ,LOS,WAN,WiFi,FXS, |
| ETH1~4,WPS,USB | |
| PON Interface | 1XPON port(EPON PX20+ and GPON Class B+) |
| SC single mode, SC/UPC connector | |
| TX optical power: 0～+4dBm | |
| RX sensitivity: -27dBm | |
| Overload optical power: -3dBm(EPON) or -8dBm(GPON) | |
| Transmission distance: 20KM | |
| Wavelength: TX 1310nm, RX1490nm | |
| User interface | 4×GE, Auto-negotiation,RJ45 ports |
| 1×POTS(2×RJ11 option) RJ11 Connector | |
| Antenna | 4T4R, 5dBi external antennas |
| USB | 1×USB 3.0 for Shared Storage/Printer |
| Management | WEB/TELNET/OAM/OMCI/TR069 |
| Support private OAM/OMCI protocol and Unified network management of SOFTEL OLT | |
| Internet connection | Support Routing Mode |
| Multicast | IGMP v1/v2/v3, IGMP snooping |
| VoIP | SIP and IMS SIP |
| Codec∶G.711/G.723/G.726/G.729 codec | |
| Echo cancellation,VAD/CNG,DTMF | |
| T.30/T.38 FAX | |
| Caller Identification/Call Waiting/Call Forwarding/Call Transfer/Call Hold/3-way Conference | |
| Line testing according to GR-909 | |
| WIFI | Support Frequency:2.4 GHz,5GHz |
| IEEE 802.11a/n/ac Wi-Fi@ 5GHz(2×2) | |
| IEEE 802.11b/g/n Wi-Fi@2.4GHz(2×2) | |
| Multiple SSIDs for each band | |
| WEP/WPA-PSK(TKIP)/WPA2-PSK(AES) Security | |
| L2 | 802.1D&802.1ad bridge, 802.1p Cos, 802.1Q VLAN |
| L3 | IPv4/IPv6, DHCP Client/Server,PPPoE, NAT,DMZ, DDNS |
| Firewall | Anti-DDOS, Filtering Based on ACL/MAC/URL |
