4GE+1*POTS+WiFi5 Dual Band 2.4G&5G EPON/GPON ONU
Model Number: ONT-4GE-V-DW
Brand: Softel
MOQ: 1
WiFi 5 Dual Band 1200Mbps
Support WEB/TELNET/OAM/OMCI/TR069
USB3.0 Interface For Shared Storage/Printer
01
Product Description
Summary and Features
If you are looking for a reliable, high-performance broadband access device that can provide you with the best Internet experience, then look no further because the ONT-4GE-V-DW can meet all your needs. This FTTH (Fiber To The Home) fiber optic network terminal is designed to provide fast and efficient internet connections, ideal for triple play services.
The device has a range of features that make it the perfect solution for any Cable TV/IPTV/FTTH network operator. The ONT-4GE-V-DW is specially designed to meet the needs of fixed network operators. It is equipped with powerful ZTE XPON and MTK Wi-Fi chipsets, making it compatible with XPON dual-mode technology (EPON and GPON), providing high-speed data services for carrier-grade FTTH applications. It also supports IEEE802.11b/g/n/ac WiFi technology and other Layer 2/Layer 3 functions to ensure a fast and stable wireless connection.
In addition, ONT is also equipped with USB3.0 interface for shared storage/printer, which is the perfect solution for home office and small business. Other useful functions of ONT-4GE-V-DW include supporting WEB/TELNET/OAM/OMCI/TR069 protocols, ensuring easy configuration and management of various services of ONT on SOFTEL OLT. High reliability, easy management and maintenance, to ensure the QoS of various services. The equipment complies with a series of international technical standards such as IEEE802.3ah and ITU-T G.984, and is compatible with most network equipment, such as HUAWEI/ZTE/FIBERHOME/VSOL.
In summary, the ONT-4GE-V-DW is a high-performance solution that provides reliable and fast internet connectivity, ideal for triple-play services. It is equipped with a powerful chip solution, compatible with various wireless connection technologies, easy to manage and maintain, high in reliability, and complies with many international standards. Whether you are a fixed network operator, a home office or a small business, the ONT-4GE-V-DW optical network terminal equipment is the perfect solution for your broadband access needs.
| ONT-4GE-V-DW 4GE+1*POTS+WiFi5 Dual Band 2.4G&5G EPON/GPON ONU | |
| Hardware Parameters | |
| Dimension | 205mm×140mm×37mm(L×W×H) |
| Net weight | 0.32Kg |
| Operating Condition | Operating temp:0 ~ +55°C Operating humidity:5 ~ 90% (non-condensed) |
| Storing Condition | Storing temp: -30 ~ +60°C Storing humidity: 5 ~ 90% (non-condensed) |
| Power Adapter | DC 12V,1.5A, external AC-DC power adaptor |
| Power supply | ≤10W |
| Interface | ONT-4GE-V-DW: 4GE+1POTS+USB3.0+WiFi5 |
| ONT-4GE-2V-DW:4GE+2POTS+USB3.0+WiFi5 | |
| Indicators | PWR, PON, LOS, WAN, WiFi, FXS, ETH1~4, WPS, USB |
| Interface Specifications | |
| PON Interface | 1XPON port(EPON PX20+ and GPON Class B+) |
| SC single mode, SC/UPC connector | |
| TX optical power: 0～+4dBm | |
| RX sensitivity: -27dBm | |
| Overload optical power: -3dBm(EPON) or -8dBm(GPON) | |
| Transmission distance: 20KM | |
| Wavelength: TX 1310nm, RX1490nm | |
| User interface | 4×GE, Auto-negotiation,RJ45 ports |
| 1×POTS(2×RJ11 Option) RJ11 Connector | |
| Antenna | 4T4R, 5dBi external antennas |
| USB | 1×USB 3.0 for Shared Storage/Printer |
| Functional Features | |
| Management | WEB/TELNET/OAM/OMCI/TR069 |
| Support private OAM/OMCI protocol and Unified network management of SOFTEL OLT | |
| Internet connection | Support Routing Mode |
| Multicast | IGMP v1/v2/v3, IGMP snooping |
| VoIP | SIP and IMS SIP |
| Codec: G.711/G.723/G.726/G.729 codec | |
| Echo cancellation,VAD/CNG,DTMF | |
| T.30/T.38 FAX | |
| Caller Identification/Call Waiting/Call Forwarding/Call Transfer/Call Hold/3-way Conference | |
| Line testing according to GR-909 | |
| WIFI | Support Frequency:2.4 GHz,5GHz |
| IEEE 802.11a/n/ac Wi-Fi@ 5GHz(2×2) | |
| IEEE 802.11b/g/n Wi-Fi@2.4GHz(2×2) | |
| Multiple SSIDs for each band | |
| WEP/WPA-PSK(TKIP)/WPA2-PSK(AES) Security | |
| L2 | 802.1D&802.1ad bridge, 802.1p Cos, 802.1Q VLAN |
| L3 | IPv4/IPv6, DHCP Client/Server,PPPoE,NAT, DMZ, DDNS |
| Firewall | Anti-DDOS, Filtering Based on ACL/MAC/URL |
