SWR-4GE3063 Speed Up 3Gbps 4*GE LAN AX3000 Wireless WiFi6 Router
Model Number: SWR-4GE3063
Brand: Softel
MOQ: 1
Next-Gen Gigabit Wi-Fi, Speed up to 3Gbps
Intel® CPE Wi-Fi Chipset, WiFi6 Gig+ Performance
OFDMA + MU-MIMO, Connect More Devices
01
Product Description
Chipset
Intel® CPE Wi-Fi Chipset WiFi6 Gig +
Speed
Next-Gen Gigabit WiFi, Speed up to 3 Gbps
Connection
Connect More Devices by OFDMA + MU-MIMO
Coverage
Maximized Coverage Beamforming
Brief Introduction
4GE+WiFi6 AX3000 Wireless Router adopts WiFi6 technology which has redefined home Wi-Fi. Experience up to 3x faster speeds, higher capacity, and reduced congestion overall compared to the previous AC WiFi5 standard. The AX3000 4-stream dual-band WiFi6 wireless router reaches speeds of up to 3Gbps, for a buffer-free 4K/HD streaming and gaming experience. The WiFi6 router lets you connect even more devices via OFDMA technology, minimizing network congestion that occurs with too many connected devices. Intel's dual-core processor effortlessly handles all your streaming, gaming, and smart home devices. SWR-4GE3063 uses Beamforming technology to focus Wi-Fi signal to your devices for more reliable coverage.
|
Item |
4*LAN WIFI 6 ROUTER |
|
Protocol |
Supports standard 802.11ax, concurrent 802.11ax and 802.11a/b/g/n/ac |
| Operating Bands | 802.11b/g/n/ax: 2.4G ~ 2.4835GHz |
| 802.11a/n/ac/ax: 5G: 5.150～5.350GHz, 5.725～5.850GHz | |
| Spatial Streams | Up to 4: 2×2: 2 in 2.4GHz , 2×2: 2 in 5GHz |
| Max Throughput | 2.4G+5G operation mode; Maximum throughput per AP: 2.974Gbps,Radio1: 2.4G 0.574Gbps, Radio2: 5G 2.4Gbps |
| Modulation | DSSS: DBPSK@1Mbps, DQPSK@2Mbps and CCK@5.5/11Mbps |
| OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps | |
| MIMO-OFDM: QPSK, 16QAM, 64QAM, 256QAM, 1024QAM | |
| Transmit Power | <25.5dBm |
| (vary depending on different countries) | |
| RAM | 256MB |
| flash | 128MB |
| Dimensions (W x D x H) | 208mm×128mm×158mm |
| Weight | ≤0.4Kg(Unit weight) |
| Installation Mode | Desktop |
| Service Ports | 1 10/100/1000M WAN port, 4 10/100/1000M LAN ports |
| Power Supply | Local power supply (DC 12V) |
| Temperature | Operating Temperature: -5°C to 40°C |
| Storage Temperature: -40°C to 70°C | |
| Humidity | Operating Humidity: 5% to 95% (non-condensing) |
| Storage Humidity: 5% to 95% (non-condensing) | |
| Power Consumption | ＜15W |
| Safety Standard | GB4943,EN60950-1, IEC60950-1 |
| EMC Standard | GB9254,GB17618, EN301 489-1, EN301 489-17 |
| Radio Standard | EN300 328, EN301 893 |
| Working Mode | Routing Mode, Bridge Mode, Wireless Repeater |
| Netwrok Setting | Desplay of Network Information |
| Support ipv4 address setting | |
| Support ipv6 address setting | |
| WLAN Setting | Support enable/disable WLAN |
| Support multi SSID setting | |
| Support SSID hiding | |
| Support SSID Name setting | |
| Support SSID encryption setting | |
| Data frame filtering | Support Whitelist, blacklist |
| Intranet settings | Support local area network settings |
| Support DHCP server settings | |
| Support advanced settings (IPv4 / v6 multicast, UPnP) | |
| advanced setting | Support STA control |
| Support WPS | |
| Support 5G Priority (Band Steering) | |
| Support WLAN roaming | |
| Other Function | Support Firewall setting |
| Support network time setting | |
| Support backup and recovery | |
| Support to change login password | |
| Support to upgrade firmware | |
| Support to restart and reset to factory | |
| Support to display Product information | |
| Support to switch network mode | |
| Multicast Service | IPTV |
| Ipv4/v6 multicast |
WiFi6 Router_SWR-4GE3063 Datasheet-V2.0-EN
