1310nm 10mW CATV Mini Fiber Optical Transmitter for Small Network
Model Number: ST1015-10mW
Brand: Softel
MOQ: 1
Small Size Wall-mounted
Single-mode Fiber High Return Loss
DFB Coaxial Small Package Laser 10mW
01
Product Description
Experience an ultra-fast and reliable internet connection with our 1310nm 10mW CATV Micro Fiber Optic Transmitter. Our products are specially designed for FTTH (fiber-to-the-home) networks, ensuring you receive uninterrupted Internet service. Our products have excellent linearity and flatness to provide a consistently strong and stable internet connection.
It uses single-mode fiber high return loss to optimize signal strength and minimize interruptions, even over long-distance connections. Our products feature GaAs amplifier active devices and ultra-low noise technology to ensure you experience top-notch performance. DFB coaxial small package lasers also enhance reliability, ensuring you can easily and quickly connect to the Internet. Our products not only perform well, but are also designed to be easy to install. The smaller size of our product means it fits easily into most spaces, making installation a breeze. Our product features a red LED power indicator, allowing you to quickly check the status of your internet connection at a glance.
Choose this 1310nm Mini Fiber Optic Transmitter and experience the best Internet connection for your home. Visit us today to learn more about our products or contact us to answer any questions you may have.
|
Number Item |
Unit |
Description |
Remark |
| Customer Interface | |||
| RF Connector | F-female | ||
| Optical Connector | SC/APC | ||
| Power Supply | F-female | ||
| Optical Parameter | |||
| Optical Return Loss | dB | ≥45 | |
| Output Optical Wavelength | nm | 1310 | |
| Output Optical Power | mW | 10 | |
| Optical Fiber Type | Single Mode | ||
| RF Parameter | |||
| Frequency Range | MHz | 47-1000 | |
| Flatness | dB | ±0.75 | |
| RF Input Level | dBµV | 80±5 | |
| Input Impedance | Ω | 75 | |
| Return Loss | dB | ≥16 | |
| C/N | dB | ≥52 | |
| CSO | dB | ≥60 | |
| CTB | dB | ≥63 | |
| Other Parameter | |||
| Power Supply | VDC | 12 | |
| Power Consumption | W | <2 | |
| Dimensions | mm | 100*98*28 | |
ST1013-10mW 1310nm CATV Mini Optical Transmitter Data Sheet.pdf
